Designs
| Design | Where to use |
|---|---|
| Plastic housing | air in chambers, refrigerators, thermal containers; temperature, or temperature and humidity |
| Sealed steel sleeve | immersion in non-aggressive liquids, product simulators, high-humidity locations |
Works with
- Smartag TZ — reusable temperature indicator with a remote probe: the device outside, the probe at the measuring point.
- Monitoring systems with an I2C interface — the same sensor for mapping and continuous monitoring.
Specifications
| Purpose | remote sensor for temperature, or temperature and humidity |
| Interface | digital, I2C |
| Length | 120 to 500 mm |
| Design | plastic housing or sealed steel sleeve |
| Metrological characteristics | as part of Smartag TZ: temperature −30…+70 °C, ±0.5 °C up to +40 °C; humidity 5–95 %, ±5 % |
| Instrument type | Smartag recording temperature indicators, State Register No. 91745-24, Smartag Zond modification |
| Manufacturer | Hladverk Group LLC |
Want to connect Smartag Zond to your monitoring system? Tell us the controller model — we will check interface compatibility.
Frequently asked questions
Can the probe be bought separately?
Yes. Smartag Zond is also supplied separately — as a replacement, in another length or for a monitoring system.
Can the probe be immersed in liquid?
The sealed steel sleeve version — yes, in non-aggressive liquids.
Which systems does it connect to?
Smartag TZ and monitoring systems with a digital I2C interface.
